Description
Program BoxProduct Functions:
1. Servo parameters setting
2. Connect the computer to set the servo
3. Servo testing
Features:
- Program box SP-MX082 has built-in high-performance 32-bit microprocessing, small size, simple and convenient operation.
- Connect the servo through the program box for parameter setting, so that the servo can adapt to different track conditions.
- Program box can store 20 sets different servo parameters.
- The program box has the function of central point adjustment, which makes the left and right angles of the chassis more consistent.
- Servo Testing: servo board band and narrow band PWM testing function.
- DEFAULT: one-key restore factory parameter function.
- Apply to a variety of SRT servos with programming marks, such as: BH815S, BH922S, BH927S, CH712S, D1S, W35, W45, T45, T55, T65, T75, BHX6, BHX8, BHX9, Min6
Specifications:
- Operating Voltage: 5-8.4V DC
- Idle Current: <20mA
- Operating Temperature: 0-40deg C
- Storage Temperature: -10-60deg C
- Storage Humidity: 20-75%RH
- Weight: 40g
- Dimensions: 87.0x47.0x12.0mm
