Description
SmartFit 2S LiPo Power Pack with High-Performance Features
The Spektrum™ RC 2S Smart G2 30C SmartFit LiPo Battery Pack is designed specifically for the Arrma Grom 1/14 to 1/18 scale mini RC lineup and also fits Losi NASCAR 1/12 platforms. Its 30C continuous discharge rating provides the intended balance of performance and battery capacity for these small-scale vehicles, while the SmartFit hard case adds protection with tighter tolerances than previous versions. The factory-installed IC2® connector provides a reliable connection and the data transfer needed for Spektrum Smart technology, with no soldering required.
About the 2S Smart G2 SmartFit LiPo Battery
Integrated Smart Data
An integrated memory microchip stores battery information including capacity, C rating, individual cell voltage, temperature, charge and discharge cycles, and internal resistance. It also maintains an error log for events such as overcharging, over-discharging, and overheating, allowing the battery's condition to be reviewed through a compatible Spektrum Smart charger. Auto Charge reads the pack's stored charging parameters and starts the charging process automatically, while customizable charge rates and other settings can be saved to the battery. Smart Discharge can also automatically discharge the pack to a selected storage voltage after a programmed period of 12 to 240 hours, helping prevent the battery from remaining fully charged during extended storage.
Features:
- Provides 2200mAh capacity for Arrma Grom platforms
- Delivers a 30C continuous discharge rating
- Stores battery data with an integrated microchip
- Transfers battery parameters through an IC2 connector
- Records charge cycles and battery health data
- Supports automatic discharge to storage voltage
IMPORTANT LITHIUM POLYMER SAFETY INFORMATION
- DO NOT leave a battery in your model when charging
- DO NOT leave lithium batteries unattended when charging
- ALWAYS balance charge lithium battery
- ALWAYS use a LiPo Safe charging bag/box
- YOU MUST use a Li-Poly specific charger to charge lithium batteries (NiMH or NiCD only chargers WILL NOT WORK!)
- YOU MUST not over discharge lithium battery packs
- READ & UNDERSTAND the instructions carefully before operating this battery
NOTE: When using high energy Li-Polymer Batteries, please do not over-discharge or over-charge batteries as this will result in overheated batteries. Discharging capacity can't exceed 80% of the max capacity of the pack after full charging to ensure a good cycle performance. It is recommended to fully charge a brand new battery before using and only discharge the battery 50% for the first 5 cycles. Always monitor race time and/or set a low voltage warning on ESC (End voltage cannot be lower than 3.2v per cell). Do not use a battery that has too low a voltage. Do not expose batteries to sunshine or store/charge batteries at temperatures above 35°C or in a closed car. The high-temperature environment could cause damage to the pack or make it burst. If the battery becomes hot while fast charging, high current discharging, or racing, do not charge it until it has cooled completely. Wait about 20 mins, then inspect prior to recharging.
Includes:
- (1) 2S Smart G2 30C SmartFit LiPo Battery Pack (7.4V/2200mAh) w/IC2 Connector
Needed to Complete:
- (1) Compatible Spektrum Smart Charger
Specifications
| Nominal Voltage |
7.4V (2S) |
| Capacity |
2200mAh |
| Maximum Charge Rate |
5C |
| Discharge Rates: |
|
| Continuous |
30C |
| Peak |
- |
| Cell Configuration |
2S1P |
| Watt Hours |
16.28Wh |
| Connector |
IC2 |
| Dimensions (LxWxH) |
3.94x1.34x0.79in (100x34x20mm) |
| Weight |
4.09oz (116g) |
*Tech Note: In order to read the data and access the Smart Technology features via the microchip, a Spektrum Smart Charger is required.
