Reefs RC Beast 1000 Waterproof Digital 1/5 Scale Brushless Servo HV REEFS102

    Description

    Reefs Beast 1000 Waterproof Digital 1/5 Scale Brushless Servo. This monster 1/5 scale servo is capable of up to 1080oz-in. at 8.4V and 0.08/60° sec. Package includes one servo, two servo horns and hardware.

    NOTE: BEC is not required but recommended for maximum performance.

    Features:

    • High torque high speed brushless servo
    • Magnetic angle sensor
    • Waterproof
    • Pulse width modulation control
    • Includes Reefs single and double servo horn
    Specifications:

    • Voltage: 4.8-8.4V
    • Waterproofing: 7 Point Seal
    • Mechanical Angle: No Limit
    • Material: Steel Gears/CNC Aluminum Casing
    • Bearing Type: 5 Ball Bearing
    • Wires: 22AWG
    • Weight: 10oz (285g)
    • Dimension: 2.59x1.18x2.32in (LxWxH)
    • Torque:
      • 6V: 800oz-in
      • 7.4V: 900oz-in
      • 8.4V: 1080oz-in
    • Speed:
      • 6V: 0.11/60° sec
      • 7.4V: 0.095/60° sec
      • 8.4V: 0.08/60° sec
    • Spline: 15T
    • Dead Band Width: 2uSec
    Product form

    SKU: EB-154623385004
    Barcode: 610406248977

    Free pickup in our shop(s)

    Be quick! Only 2 products left in stock!

    2 in stock Ships within 24hr of Purchase

    $389.99

      • Guaranteed secure & safe checkout.

        shop pay
      • Free shipping on orders over $150
      Pay whenever you want

      Easily pay within 30 days after you have received your package.
      Read more

      Description

      Reefs Beast 1000 Waterproof Digital 1/5 Scale Brushless Servo. This monster 1/5 scale servo is capable of up to 1080oz-in. at 8.4V and 0.08/60° sec. Package includes one servo, two servo horns and hardware.

      NOTE: BEC is not required but recommended for maximum performance.

      Features:

      • High torque high speed brushless servo
      • Magnetic angle sensor
      • Waterproof
      • Pulse width modulation control
      • Includes Reefs single and double servo horn
      Specifications:

      • Voltage: 4.8-8.4V
      • Waterproofing: 7 Point Seal
      • Mechanical Angle: No Limit
      • Material: Steel Gears/CNC Aluminum Casing
      • Bearing Type: 5 Ball Bearing
      • Wires: 22AWG
      • Weight: 10oz (285g)
      • Dimension: 2.59x1.18x2.32in (LxWxH)
      • Torque:
        • 6V: 800oz-in
        • 7.4V: 900oz-in
        • 8.4V: 1080oz-in
      • Speed:
        • 6V: 0.11/60° sec
        • 7.4V: 0.095/60° sec
        • 8.4V: 0.08/60° sec
      • Spline: 15T
      • Dead Band Width: 2uSec
