Higher Power, Lower Temperature
The new Stock Spec G2 has increased maximum current rating to 100 amps. This is 20 amps more than the previous Stock Spec. Testing has shown as much as 30 degrees Celcius lower tems under the same loads. The stability and reliability of the ESC has been further strengthened.
Built-In Polarity Protection
One danger that all electrical systems face is a reversed polarity from the power source. This can be caused by a short circuit, or usually, accidentally reversing the terminals.
Optimized Cable Outlet
The ESC input and output wires has been optimized to ensure ease of different wiring needed for both on-road and off-road vehicles.
Real-Time Data Acquisition
After the ESC is connected to the OTA Bluetooth module, connect to the ESC through the HW Link mobile app and turn on the real-time data recording function. Throttle, voltage, current, temperature, motor RPM, and more, can be viewed in real time. In addition, OTA can record the above data using HW Link.
Multi-Level Throttle and Brake Curvature
Supports a wide range of throttle and brake curvature adjustment. From an aggressive to mild throttle can be set, and fine tuned with the throttle curve. Similarly, the brake curve can be adjusted to meet the needs of the track.
Drag Brake Frequency is Independently Adjustable
The drag brake frequency can now be set independent from the standard brake frequency. The user will be able to adjust the drag brake functions accurately.
Features
- Optimized architecture, low-center-gravity.
- Maintain small foot print: 34.8x30x13.8mm
- 3 select-to-use profiles applicable to 1/10 RC car racing.
- Data logging for recording the maximum ESC/motor temperature, motor RPM, and others in real time.
Product Specifications
| Manufacturer # |
38020377 |
| Product Length |
1.37" (35 mm) |
| BEC |
Yes |
| BEC Voltage |
6V/ 7.4V Adjustable |
| Input Voltage |
2S LiPo Only |
| Motor Limit |
With 2S LiPo: > 10.5T Motor |
| Product Height |
0.54" (14 mm) |
| Product Width |
1.18" (30 mm) |
| BEC Continous Current |
5A |
| Number of Poles |
2 Pole |
| Product Weight |
2.22 oz (63g) |
| Maximum Burst Current |
500A |
| Maximum Continuous Current |
100A |
| Motor Type |
Brushless Sensored |
| Turns |
13.5T |
- Separate PRG/FAN port is able to power an external fan for maximize cooling performance or connect a LCD program box or OTA Programmer to the ESC.
- Multiple protections: low-voltage cutoff protection, ESC and motor thermal protection, and fail safe (throttle signal loss protection),reverse polarity protection.
- Firmware upgrade via Hobbywing multifunction LCD Pro program box or OTA Programmer.
