High-Performance R/C Crawling ESC
Discover unparalleled performance and innovation with the Hobbywing XeRun AXE R3, a waterproof and dustproof sensored brushless ESC that sets higher standards for rock crawlers. Designed to power crawlers from 1/10 scale to 1/6 scale, this ESC combines cutting-edge Field Oriented Control (FOC) technology, a powerful switchable internal BEC, and built-in Bluetooth connectivity for seamless programming and real-time data monitoring, making it the ultimate choice for enthusiasts seeking superior control and durability!
About the Xerun AXE R3 ESC
Technologies & Capabilities
The Hobbywing XeRun AXE R3 Waterproof Rock Crawler Sensored Brushless ESC is a remarkable blend of innovative technology and powerful performance, designed to cater to rock crawlers ranging from 1/10 scale to 1/6 scale. Utilizing Hobbywing's patented Field Oriented Control (FOC) technology, this ESC offers exceptional low-speed torque, significantly enhancing the power system of rock crawlers. The chip-type magnetic encoder within the motor ensures precise signal output, guaranteeing consistency across the three phases and delivering accurate rotor position data. Capable of running on up to 6S LiPo batteries with a continuous current of up to 135A, the AXE R3 supports 1/10th, 1/8th, 1/7th, and 1/6th scale crawlers, making it a versatile choice for hobbyists. Additionally, the dual external control channels allow for real-time parameter adjustments via the receiver's open channels, ensuring optimal performance under varying conditions.
Powerful Built-In Features
One of the standout features of the XeRun AXE R3 is its powerful internal BEC, which provides a maximum output current of 15A. This built-in BEC has switchable voltage settings between 6V, 7.4V, and 8.4V, making it suitable for a wide range of standard and high-voltage servos, as well as peripheral electrical equipment like light sets and winches. The inclusion of a built-in Bluetooth module further enhances the user experience, enabling quick and easy programming through the HW Link mobile app. This app allows for real-time data monitoring, parameter settings, firmware upgrades, and access to the ESC's built-in data logging functions, making it incredibly convenient for users to fine-tune and analyze their crawler's performance on the go.
Durable Construction
Durability is a key attribute of the AXE R3, boasting an IP67 protection rating that ensures excellent waterproof and dustproof performance. This level of protection allows the ESC to operate reliably in various climatic conditions without the risk of damage from water or dust. The smart cooling fan feature, which activates only when the ESC temperature reaches a preset threshold, helps conserve power, reduce noise, and maintain an optimal operating temperature. The robust aluminum case adds another layer of durability, while built-in protection protocols safeguard against potential damage, ensuring long-lasting performance. Together, these features make the Hobbywing XeRun AXE R3 a resilient and reliable choice for serious rock crawling enthusiasts.
Features:
- Compatible with rock crawlers from 1/10 scale all the way to 1/6 scale
- Capable of running on up to 6S LiPo battery
- Field Oriented Control (FOC) system with buttery smooth powerful torque
- Intelligent torque output and speed closed-loop control
- Super powerful switchable internal 15A BEC
- Built-in Bluetooth module & data logging functions
- Supports Flysky i-BUS2 telemetry system
- Dual external control channels, real-time adjustment of parameters
- IP67 waterproof and dust-proof design
- Smart fan start and stop function
