High-Performance 420-520 Size Heli ESC
The Hobbywing Platinum 120A V5 Brushless ESC is a top-tier electronic speed controller (ESC) designed for superior performance in electric helicopters and fixed-wing aircraft. The ESC's compact design, combined with advanced heat dissipation and cutting-edge technology, ensures optimal efficiency and reliability. With features like a high-power BEC and an RPM accuracy algorithm, this ESC provides unparalleled control and power, making it an excellent choice for demanding pilots.
About the Platinum 120A V5 Brushless ESC
Heat Dissipation
The Platinum 120A V5 Brushless ESC features a redesigned and compact form that allows it to fit into a wider range of aircraft. Its double-sided heat sink with a side vent enables air to flow quickly through the ESC, efficiently cooling it even during intense use. This innovative air duct design is combined with a powerful cooling fan that significantly enhances the ESC's cooling capability, ensuring stable performance and longevity.
High-Power BEC
This ESC comes equipped with a built-in 12V Switch BEC, offering adjustable output voltage from 5V to 12V and a maximum current output of 35 amps. The BEC includes an anti-reverse circuit, allowing it to operate in parallel with external batteries for added protection. This high-power BEC ensures reliable power delivery to the aircraft's electronics, supporting demanding flight operations with greater output capability and safety.
Advanced RPM Accuracy
Equipped with a 32-bit processor, the Platinum 120A V5 Brushless ESC utilizes an advanced RPM accuracy algorithm to deliver precise and consistent performance. This algorithm maximizes RPM accuracy and allows pilots to adjust constant speed sensitivity to their preference. Additionally, the ESC incorporates synchronous rectification driving efficiency optimization (DEO) technology, which enhances throttle response, flight stability, and overall efficiency, resulting in longer battery life and lower operating temperatures.
Features:
- Efficient heat dissipation with double-sided heat sink
- Adjustable BEC output voltage
- Anti-reverse circuit in BEC
- High-power BEC with 35A peak output current
- Enhanced throttle response and flight stability
- Advanced RPM accuracy algorithm
- Driving efficiency optimization
- 32-bit processor for powerful and precise performance
