Furitek Losi NASCAR SCORPION Brushless Sensored ESC/Motor FUR-2596

    Description

    High-Performance ESC & Motor Combo

    The Furitek SCORPION 5600KV Brushless Sensored ESC/Motor Combo delivers unmatched performance and precision for the 1/12 Losi NASCAR AWD RC truck. Designed with advanced technology, this system offers smooth throttle control, live tuning capabilities, and wireless setup through the Furicar app. Perfect for both beginners and seasoned drivers, the SCORPION combines power and efficiency to enhance your racing experience.

    About the SCORPION Brushless Combo


    Sensored and Sensorless Operation

    This combo supports both sensored and sensorless modes, offering a constant current of 40A and a burst current of 70A. The flexibility ensures superior performance across various driving conditions, making it suitable for precision driving or high-speed racing.

    Wireless Configuration and Live Tuning

    The built-in Bluetooth module enables wireless parameter adjustments via the Furicar app on Android and iOS. Real-time tuning ensures seamless customization without interrupting your drive, delivering unmatched control at your fingertips.

    Compact Design and Smooth Performance

    With a lightweight and compact build, the Furitek SCORPION system enhances agility and responsiveness. The high-torque, sensored motor ensures smooth throttle response, maximizing driving precision for consistent on-track performance.

    Features:

    • Supports sensored and sensorless modes
    • Built-in Bluetooth for wireless setup
    • Real-time tuning via the Furicar app
    • Smooth throttle control for precision driving
    • Compact, lightweight design
    • 2-3S LiPo battery compatibility
    • Free lifetime firmware updates
    • High-performance 5600Kv brushless motor
    • Real-time telemetry for performance tracking
    • Compatible with stock pinion and shaft

    Includes:

    • (1) Furitek 40/70A PASO Sensored/Sensorless ESC with built-in wireless module
    • (1) Furitek 5600KV KINETIC Brushless Sensored Motor
    • (2) Sensored Cables
    • (1) Signal Cable
    • (1) User Manual

    Specifications:

    Suggested Application 1/12
    Motor Type Brushless-Sensored
    Input Voltage 2-3S LiPo (7.4-11.1V)
    Continuous Current 40A
    Burst Current 70A
    Dimensions (LxWxH) 0.63x1.1x0.39in (16x28x10mm)
    Weight 0.53oz (15.2g)
    BEC Voltage 5.5/7.4V
    BEC Continuous Current -
    BEC Peak Current 3A
    Motor Connector 3 Pin
    Battery Connector IC2
    Motor Wire -
    Battery Wire -
    Throttle Wire -
    Programming Furicar Wireless App
    Suggested Application 1/12
    Size 5600kV
    Type Brushless-Sensored
    Voltage 2-3S LiPo (7.4-11.1V)
    Adjustable Timing -
    Watts 300
    Connector 3 Pin
    Dimensions 0.94x1.38in (24x35mm)
    Shaft Length 0.47in (12mm)
    Shaft Diameter 0.09in (2.3mm)
    Weight 1.9oz (54g)

    *Tech Note: Heat sink aluminum adaptor is not included, the angle of motor solder has been changed to fit in the Losi Nascar.

    Product form

    SKU: FUR-2596
    Barcode: 8936037010700

    Free pickup in our shop(s)

    Be quick! Only 2 products left in stock!

    2 in stock Ships within 24hr of Purchase

    $99.99

      • Guaranteed secure & safe checkout.

        shop pay
      • Free shipping on orders over $150
      Pay whenever you want

      Easily pay within 30 days after you have received your package.
      Read more

      Description

      High-Performance ESC & Motor Combo

      The Furitek SCORPION 5600KV Brushless Sensored ESC/Motor Combo delivers unmatched performance and precision for the 1/12 Losi NASCAR AWD RC truck. Designed with advanced technology, this system offers smooth throttle control, live tuning capabilities, and wireless setup through the Furicar app. Perfect for both beginners and seasoned drivers, the SCORPION combines power and efficiency to enhance your racing experience.

      About the SCORPION Brushless Combo


      Sensored and Sensorless Operation

      This combo supports both sensored and sensorless modes, offering a constant current of 40A and a burst current of 70A. The flexibility ensures superior performance across various driving conditions, making it suitable for precision driving or high-speed racing.

      Wireless Configuration and Live Tuning

      The built-in Bluetooth module enables wireless parameter adjustments via the Furicar app on Android and iOS. Real-time tuning ensures seamless customization without interrupting your drive, delivering unmatched control at your fingertips.

      Compact Design and Smooth Performance

      With a lightweight and compact build, the Furitek SCORPION system enhances agility and responsiveness. The high-torque, sensored motor ensures smooth throttle response, maximizing driving precision for consistent on-track performance.

      Features:

      • Supports sensored and sensorless modes
      • Built-in Bluetooth for wireless setup
      • Real-time tuning via the Furicar app
      • Smooth throttle control for precision driving
      • Compact, lightweight design
      • 2-3S LiPo battery compatibility
      • Free lifetime firmware updates
      • High-performance 5600Kv brushless motor
      • Real-time telemetry for performance tracking
      • Compatible with stock pinion and shaft

      Includes:

      • (1) Furitek 40/70A PASO Sensored/Sensorless ESC with built-in wireless module
      • (1) Furitek 5600KV KINETIC Brushless Sensored Motor
      • (2) Sensored Cables
      • (1) Signal Cable
      • (1) User Manual

      Specifications:

      Suggested Application 1/12
      Motor Type Brushless-Sensored
      Input Voltage 2-3S LiPo (7.4-11.1V)
      Continuous Current 40A
      Burst Current 70A
      Dimensions (LxWxH) 0.63x1.1x0.39in (16x28x10mm)
      Weight 0.53oz (15.2g)
      BEC Voltage 5.5/7.4V
      BEC Continuous Current -
      BEC Peak Current 3A
      Motor Connector 3 Pin
      Battery Connector IC2
      Motor Wire -
      Battery Wire -
      Throttle Wire -
      Programming Furicar Wireless App
      Suggested Application 1/12
      Size 5600kV
      Type Brushless-Sensored
      Voltage 2-3S LiPo (7.4-11.1V)
      Adjustable Timing -
      Watts 300
      Connector 3 Pin
      Dimensions 0.94x1.38in (24x35mm)
      Shaft Length 0.47in (12mm)
      Shaft Diameter 0.09in (2.3mm)
      Weight 1.9oz (54g)

      *Tech Note: Heat sink aluminum adaptor is not included, the angle of motor solder has been changed to fit in the Losi Nascar.
