| Technical Specs |
|---|
| Input Voltage Range: |
MIN: 3S LiPo
MAX: 8S LiPo (33.6v) |
| BEC Specifications: |
5.5V to 8.5V adjustable in 0.1V increments (20A peak), default 5.5V |
| Application Guidelines: |
Designed for use in 1/7th and 1/5th scale RC vehicles. The Cobra 5 is not intended for drag racing applications and the one-year warranty does not cover the use of the system outside if its intended use. Improper setup or use of this product can result in catastrophic failures of the motor, esc and/or batteries. |
| Running Modes: |
SmartSense™ and Sensorless |
| Reversible: |
Yes, but may be disabled for racing.
|
| On/Off Switch: |
Yes, waterpoof |
| Cooling Fan: |
Yes, factory equipped (50mm), temperature controlled
|
| Size (L x W x H): |
3.98" x 2.49" x 2.35" (101.2mm x 63.3mm x 59.5mm) |
| Weight (without wires): |
13.2 oz (374 grams) |
| Connectors: |
8.0mm female bullets for motor connection.
|
| Items Needed for Operation: |
A high current connector designed for high-powered electric systems, rated for 150+ amps, such as Castle QS8 8mm Anti Spark, or QS10 10mm Anti Spark soldered to the battery leads.
Castle has tested and recommends the following batteries. There are other batteries that will work, but these are the ones we have tested with:
GensAce 10,000mAh & 6800mAh G-Tec Advanced 100C
GenSace 11,000mAh & 6800mAh G-Tec Bashing 100/120C
SMC 9500mAh, 8200mAh & 7600mAh HCL-HP 150C
SMC 10,600mAh & 8600mAh SRD 250C
|
| Installation: |
Mounting holes located on the bottom of aluminum case for installation into vehicle |
| Recommended Motors: |
Castle 2028-800Kv, 2028-1100Kv, 1721-1260Kv |
| Programmability: |
Access to tuning options and firmware updates for free with Castle Link V4 USB adapter included with purchase. Now with USB-C connector! (Requires Windows 10 or higher) |
| Operating Environment: |
- Although Cobra 5 is waterproof, it is not intended for operation while completely submerged in liquid.
- Always rinse the ESC and motor with clean water after exposure to corrosives or dirt.
- While the motor and controller may be waterproof, we suggest users confirm that the rest of their vehicle, including the batteries, servos, radio and chassis are also waterproof before exposing them to liquids of any kind.
- The cooling fan must be removed prior to driving in wet conditions. It is not waterproof.
|
| Product Use Statements: |
|
| Input Voltage Range: |
10S max (8S with Cobra 5) |
| Kv: |
1260 |
| Max. RPM: |
45,000 |
| Motor Size: |
Length: 101.2mm
Diameter: 47.6mm |
| Shaft Size: |
Length: 22mm
Diameter: 8mm |
| Weight (w/wires): |
27.36 oz. / 1.71 lbs |
| Mounting Hole Specifications: |
M3 and M4 @ 25.4mm |
| Cooling Fan: |
Available for purchase |
| Connectors: |
8.0mm male bullets, 250mm sensor wire
|
| Items Needed for Operation: |
N/A |
| Product Use Statements: |
N/A |
| Application Guidelines: |
For 1:7 scale vehicles weighing up to 25lbs. and up to 8s LiPo. |
| Max. Recommended Vehicle Weight: |
25 lbs |
| Tech Notes: |
- Routine maintenance is recommended after running in wet conditions.
- Monitor motor temperatures closely; overheating a motor will cause permanent damage to the magnets. Never exceed 200° F on the the motor or ESC.
- Do not use mounting screws that extend more than 5mm into the front of the motor. Using too long of a screw can result in damage to the motor's windings and will not be covered by the warranty.
|
